Technical Specifications
Rated Output Power: 6.2 kW / 6.2 kVA (Pure Sine Wave)
Nominal System Voltage: 48 VDC battery input
Max Solar Array (PV) Input Power: 6,000 Watts
MPPT Voltage Range: 60V to 450V DC (Maximum Open Circuit Voltage: 500V DC)
Max Charging Current: 120A Solar (MPPT) + 100A AC charging
Output Voltage: 230V AC ± 10% at 50/60Hz
Peak Efficiency: 93%
âš™ Core Functionality
Hybrid Operation: It seamlessly manages energy between three sources: Solar panels, Utility Grid/Generator, and Batteries.
Battery-Free Operation: Capable of powering your home loads directly from your solar panels during the day even if no physical battery bank is connected.
